  • Flip cooker – FDA

    • Flip cooker – FDA

    • Is part of our wide range of food cookers for preparation and homogenization .
    • It is considered one of the essential equipment in the food industry, as it is used in the preparation and homogenization of low- and high-viscosity foods (sauces, processed cheese, jams, toffee, caramel, etc.)
    • The mixing chamber is spherical in shape and has a double-jacketed bottom (heating).
    • all points welded by TIG & ORBITAL polished and treated.
    • Product contact parts made of SS (316 L) and structure parts made of SS ( 304 ).
    • Interior surface of Spherical cooker is a Matt finishing and exterior surface is a Matt finishing .
    Categories , , Tags ,

    Flip cooker’s main parts:

    • Automatically moveable upper body, equipped with:
    1. A central mixing mechanism with a distinctive design to give the best mixing results. It is equipped with Teflon scrapers to scrape the inner wall of the cooker. The mechanism is driven by a motor and a speed reducer.
    • Mixing chamber, equipped with:
    1.  The upper part of the chamber has a directed path for discharging the product.
    2. A tipping mechanism for the mixing chamber to complete the emptying process manually.
    3. A temperature sensor to read the temperature of the product.
    4.  Slot equipped to:
      • Heating medium inlet (steam)
    5. The opening is equipped with safety valve and pressure watch for Double jacket.
    •  Mixer base:
    1. Slot equipped to:
      • Heating medium outlet (steam condensation)
    2. Equipped with calibrated bases.
    Single Layer Tank – cGMP
    , , , ,
    Single Layer Tank – cGMP
    Top Homogenizer T-MSC
    , , , ,
    Top Homogenizer T-MSC
    Pro Mixer – cGMP
    , ,
    Pro Mixer – cGMP
    • Flip cooker featured by high efficiency, ease of use and low maintenance.
    • The Cooker is designed and manufactured in accordance with international quality systems .
    • The production capacity varies depending on the type and density of the product.
    • The Cooker can be designed to meet exact customer requirements.
    • Documentation and protocols ( DQ–IQ–OQ–FAT–SAT).
    • After-sales services include maintenance operations and constant availability of spare parts.
